OBED GVR Performance Gravel Bike

Name: OBED GVR Performance Gravel Bike
Brand: OBED Bikes
SKU: GVR
Price: 3799.0 USD
Availability: InStock

See the OBED GVR Performance Gravel Bike overview

Component requests

Note any additional requests here

Your total:

Your build highlights

Built For You

Customize your bike with your preferred drivetrain and components. Create a custom color scheme by choosing your paint and decals.

Learn more

Expert Help

Have questions? Our team of experts is ready and waiting to help. Simply call, email, or chat with us and get the answers you seek.

Learn more

Easy Financing

Turn your dream bike into reality with easy financing, quick approvals, and low monthly payments that fit your budget.

Learn more

Explore the details

In the pursuit of more speed (and more fun) on dirt, gravel, and pavement, we sought every advantage: better aerodynamics, lighter weight, more stiffness, and exceptional comfort. We wanted to give you no excuses—whether on race day or your weekend romp. We wanted hidden cables, ample tire clearance, and precise handling. In short, we wanted it all—and we found it in the GVR

Carbon Fork

Our full-carbon adventure gravel fork is designed with performance, compliance and versatility in mind:

Fork Steer Tube Diameter: 1 1/8” to 1 1/2” tapered
Axle Spacing: 12 x 100mm
Compatible Rotor sizes: 140 and 160mm

Elevate your off-road experience with a fork that combines precision, comfort, adaptability, and style.

Bar, Stem + Crank Specs

Size XS - Bar: 42cm; Stem: 90mm; Crank: 170

Size S - Bar: 42cm; Stem: 90mm; Crank: 170

Size M - Bar: 44cm; Stem: 100mm; Crank: 170

Size L, XL - Bar: 46cm; Stem: 110mm; Crank: 170

Select a build kit:

Groupset	Shimano GRX 820 1X 12 Spd
Headset	Cane Creek
Handlebar	FSA A-Wing AGX Alloy
Seatpost	Select in Builder
Shifters	Shimano GRX RX820 12 spd
Crankset	Shimano GRX RX820 1x 40T
Chain	Shimano M8100 12 spd
Tires	Select in Builder
Brakeset	Shimano GRX RX820 Hydraulic
Stem	FSA Energy
Saddle	Select in Builder
Rotors	Shimano CL800 160mm
Rear derailleur	Shimano GRX RX822 12 spd
Cassette	Shimano XT M8100 10-51 12 spd
Bottom bracket	BB86 Press-Fit
Wheelset	Select in Builder
Fork	Select in Builder

Groupset	Shimano GRX 820 2X 12 Spd
Headset	Cane Creek
Handlebar	FSA A-Wing AGX Alloy
Seatpost	Select in Builder
Shifters	Shimano GRX RX820 12 spd
Front derailleur	Shimano GRX RX820
Crankset	Shimano GRX RX820 48/31
Chain	Shimano M8100 12 spd
Tires	Select in Builder
Brakeset	Shimano GRX RX820 Hydraulic
Stem	FSA Energy
Saddle	Select in Builder
Rotors	Shimano CL800 160mm
Rear derailleur	Shimano GRX RX820 12 Spd
Cassette	Shimano Ultegra R8100 11-34T 12 spd
Bottom bracket	BB86 Press-Fit
Wheelset	Select in Builder
Fork	Select in Builder

Groupset	Shimano GRX 825 Di2 12 Spd
Headset	Cane Creek
Handlebar	FSA A-Wing AGX Alloy
Seatpost	Select in Builder
Shifters	Shimano GRX RX825 Di2 12 spd
Front derailleur	Shimano GRX RX825 Di2
Crankset	Shimano GRX RX820 48/31
Chain	Shimano M8100 12 spd
Tires	Select in Builder
Brakeset	Shimano GRX RX820 Hydraulic
Stem	FSA Energy
Saddle	Select in Builder
Rotors	Shimano CL800 160mm
Rear derailleur	Shimano GRX RX825 Di2
Cassette	Shimano Ultegra R8100 11-34T 12 spd
Bottom bracket	BB86 Press-Fit
Wheelset	Select in Builder
Fork	Select in Builder

	XS	S	M	L	XL
Top Tube Length	518mm	527mm	544mm	560mm	581mm
Head Tube Length	115mm	128mm	146mm	170mm	192mm
Seat Tube Angle	74.5˚	74.5˚	74.0˚	73.5˚	73.0˚
Head Tube Angle	70.5˚	70.5˚	71.5˚	72.0˚	72.0˚
BB Drop	72mm	72mm	71mm	68mm	67mm
Chainstay Length	425mm	425mm	425mm	425mm	425mm
Wheelbase	1010mm	1016mm	1014mm	1026mm	1043mm
Front Center	596mm	601mm	600mm	611mm	628mm
Standover Height	74.5cm	76.9cm	80.7cm	83.7cm	86.3cm
Fork axle to crown	395mm	395mm	395mm	395mm	395mm
Fork rake	50mm	50mm	50mm	50mm	50mm
Seat Tube Length	460mm	490mm	520mm	550mm	580mm
Reach	370mm	375mm	380mm	385mm	395mm
Stack	534mm	548mm	570mm	590mm	610mm

Xs

60cm 152 - 64cm 163

S

63cm 160 - 67cm 170

M

66cm 168 - 70cm 178

Ml

69cm 175 - 73cm 185

L

72cm 183 - 76cm 193

The GVR is our lightweight gravel race bike, built for riders who want a competitive advantage on fast gravel roads. It uses a lightweight frame with an efficient yet compliant carbon lay-up and geometry tuned for agility and control, making it perfect for high-speed endurance gravel riding and racing.

The GVR fits tires up to 700c x 45mm wide or 650b x 53mm wide.

Yes! The GVR is also fast and efficient on the road. If you choose to install road tires on your GVR, we recommend using tires at least 700c x 32mm wide to reduce the effect smaller tires will have on the geometry.

The GVR comes with tubeless-ready wheels and tires and is shipped set up tubeless with sealant from the factory.

The GVR does not have built-in rack mounts, but rack mounts can be added to the GVR frame by purchasing a Removable Rack/Fender seatstay bridge hardware kit. This kit allows you to install fenders and/or a rack.

We can install a gravel suspension fork as a custom component request. The GVR, however, does not use suspension-corrected geometry, so be aware that a suspension fork will lift the front end, altering the geometry and handling.

To modify the GVR for external routing, submit a custom component request.

If you're on the border of two sizes, the right size may depend on certain body measurements and your riding style. Feel free to contact us at any time regarding sizing questions - our product specialists are experienced with finding riders the right fit by cross-referencing your information with our fit database.

If you're not transferring measurements from a similar bike, to get completely "dialed in" for maximum performance, we recommend you see a reputable professional bike fitter that can fit you to your new bike.

Custom requests can be submitted through the “Component Requests” box in our bike builder, or you can contact us at any time to inquire about custom requests. A member of our team will reach out for additional information. All custom requests are subject to availability, and additional charges may apply.
