OBED MMR GRX 810 Adventure Gravel Bike

Made to Order Assembly + Shipping

|

Lead Time 2 Weeks

These components are required:

Your total:

Your total:

Your build highlights

Extreme Customization
Built For You
Customize your bike with your preferred drivetrain and components. Create a custom color scheme by choosing your paint and decals.
Learn more
Integration
Expert Help
Have questions? Our team of experts is ready and waiting to help. Simply call, email, or chat with us and get the answers you seek.
Learn more
Multiple overlapping circles, decreasing in size from left to right
Easy Financing
Turn your dream bike into reality with easy financing, quick approvals, and low monthly payments that fit your budget.
Learn more

Explore the details

Your definition of the perfect ride could take you… anywhere. Riders who find fun on the most remote, rugged, and unknown roads require a bike designed to get them there. Named for the “Minimum Maintenance Road” signs that off-grid riders become so familiar with, we gave the MMR 2.25” tire clearance, suspension-corrected geometry, and an internal storage bay, making it the most rugged, capable, and fun gravel adventure bike in the OBED line-up.

  • 29” x 2.25” / 57mm tire clearance
  • Suspension corrected geometry
  • Rack and frame bag mounts
  • Downtube storage bay
  • Universal derailleur hanger
  • T47 Outboard bottom bracket
  • Integrated and non-integrated cable routing options

Select a build kit:

Groupset Shimano GRX 820 1X 12 Spd
Headset FSA 55R 1.5" ACR
Stem FSA SMR
Handlebar Select in Builder
Seatpost Select in Builder
Saddle Select in Builder
Shifters Shimano GRX RX820 12 spd
Rotors Shimano CL800 160mm
Front derailleur N/A
Rear derailleur Shimano GRX RX822 12 spd
Crankset Shimano GRX RX820 1x 40T
Cassette Shimano XT M8100 10-51 12 spd
Chain Shimano M8100 12 spd
Bottom bracket T47 Outboard
Tires Select in Builder
Brakeset Shimano GRX RX820 Hydraulic
Wheelset Select in Builder
Fork Select in Builder
Groupset Shimano GRX 827 Di2 1x 12 Spd
Headset FSA 55R 1.5" ACR
Stem FSA SMR
Handlebar Select in Builder
Seatpost Select in Builder
Saddle Select in Builder
Shifters Shimano GRX RX825 Di2 12 spd
Rotors Shimano CL800 160mm
Front derailleur N/A
Rear derailleur Shimano GRX RX827 12 spd
Crankset Shimano GRX RX820 1x 40T
Cassette Shimano XT M8200 10-51  12 spd
Chain Shimano M8100 12 spd
Bottom bracket T47 Outboard
Tires Select in Builder
Brakeset Shimano GRX RX820 Hydraulic
Wheelset Select in Builder
Fork Select in Builder
Groupset SRAM Rival XPLR E1
Headset FSA No 55R
Stem FSA ACR
Handlebar Select in Builder
Seatpost Select in Builder
Saddle Select in Builder
Shifters SRAM Rival E1 AXS
Rotors SRAM Paceline 160mm
Front derailleur N/A
Rear derailleur SRAM Rival XPLR AXS E1 13spd
Crankset SRAM Rival XPLR E1 AXS 40T
Cassette SRAM Rival XPLR 10-46T 13 spd
Chain SRAM Rival
Bottom bracket T47 Outboard
Tires Select in Builder
Brakeset SRAM Rival eTap AXS HRD
Wheelset Select in Builder
Fork Select in Builder
Groupset SRAM Force XPLR E1
Headset FSA No 55R
Stem FSA ACR
Handlebar Select in Builder
Seatpost Select in Builder
Saddle Select in Builder
Shifters SRAM Force E1 AXS
Rotors SRAM Paceline 160mm
Front derailleur N/A
Rear derailleur SRAM Force D2 AXS XPLR 12spd
Crankset SRAM Force XPLR E1 AXS 42T Power Meter
Cassette SRAM Rival XPLR 10-46T 13 spd
Chain SRAM Rival 12 spd
Bottom bracket T47 Outboard
Tires Select in Builder
Brakeset SRAM Force D2 HRD
Wheelset Select in Builder
Fork Select in Builder
Groupset SRAM Red XPLR E1
Headset FSA No 55R
Stem FSA ACR
Handlebar Select in Builder
Seatpost Select in Builder
Saddle Select in Builder
Shifters SRAM RED E1 AXS
Rotors SRAM Paceline X 160mm
Front derailleur N/A
Rear derailleur SRAM RED XPLR AXS E1 13spd
Crankset SRAM RED XPLR E1 AXS 42T Power Meter
Cassette SRAM RED XPLR 10-46T 13 spd
Chain SRAM RED
Bottom bracket T47 Outboard
Tires Select in Builder
Brakeset SRAM RED E1 HRD
Wheelset Select in Builder
Fork Select in Builder
XS S M L
Stack 540mm 560mm 580mm 600mm
Reach 370mm 380mm 390mm 400mm
Virtual tt length 52˚ 54.1˚ 56.2˚ 57.8˚
Head Tube Length 95mm 114mm 135mm 157mm
Seat Tube Length 430mm 460mm 490mm 525mm
Head Tube Angle 69˚ 69.5˚ 70˚ 70˚
Seat Tube Angle 74.5˚ 74˚ 73.5˚ 73.5˚
Chainstay Length 440mm 440mm 440mm 440mm
BB Drop 76mm 76mm 74mm 74mm
Wheelbase 1035mm 1048mm 1061mm 1078mm
Front Center 606mm 619mm 632mm 649mm
Fork offset 50mm 50mm 50mm 50mm
Standover Height 715mm 749mm 805mm 834mm
Xs
152cm 4'11" - 163cm 5'4"
S
160cm 5'2" - 170cm 5'6"
M
168cm 5'6" - 178cm 5'11"
L
183cm 5'11" - 193cm 6'3"

The MMR is our gravel adventure bike, built for riders who want to explore rough gravel roads and trails. It uses a purpose-built frame with robust yet compliant carbon lay-up, internal storage, and geometry tuned for comfort, making it perfect for long-distance adventures and technical terrain.

We placed the internal storage door on the underside of the downtube for easier access when the frame is loaded with bags. It allows riders to access their internal storage without removing any bottles or frame bags. It also doubles as a protective bash guard.

With the factory liner installed to prevent noise, the storage capacity is 0.8 liters. We are able to fit our MMR tool roll (sold separately) with enough room for a tube and a lightweight shell. The liner is removable for cleaning or if riders want to fit more gear inside the frame.

Yes! The MMR can be used as a gravel racer, especially on extremely rough or technical courses, or if you are looking for the extra comfort and confidence that larger tires provide.

Yes! The MMR is a do-it-all bike and will be competent on the road. If you choose to install road tires on your MMR, we recommend using tires at least 700c x 40mm wide to reduce the effect smaller tires will have on the geometry.

The MMR frame and Adventure Fork fit tires up to 700c x 57mm / 29 x 2.25” wide. Fox 32 Taper-Cast and Cane Creek Invert gravel suspension forks are officially rated for 700c x 50mm tires. With a 2x drivetrain, tire clearance is limited to 700c x 48mm due to the front derailleur. The MMR is not designed for 650b wheels and tires.

The MMR comes with tubeless-ready wheels and tires and is shipped set up tubeless with sealant from the factory.

Yes! The MMR uses suspension-corrected geometry and is compatible with all standard gravel suspension forks on the market.

Yes! The MMR is compatible with internally routed dropper seatposts.

Yes! The MMR has built-in rear rack mounts. Rigid forks come with additional gear mounts on the fork legs.

An MMR equipped with the base-level Shimano GRX 810 2x drivetrain will be set up from the factory with external cable routing. To modify the MMR for external routing with other drivetrains, submit a custom component request.

Custom requests can be submitted through the “Component Requests” box in our bike builder, or you can contact us at any time to inquire about custom requests. A member of our team will reach out for additional information. All custom requests are subject to availability, and additional charges may apply.

If you're on the border of two sizes, the right size may depend on certain body measurements and your riding style. Feel free to contact us at any time regarding sizing questions - our product specialists are experienced with finding riders the right fit by cross-referencing your information with our fit database.

If you're not transferring measurements from a similar bike, to get completely "dialed in" for maximum performance, we recommend you see a reputable professional bike fitter that can fit you to your new bike.

Built for You

OBED was born out of the team behind legendary titanium and triathlon brands in Chattanooga, Tennessee. After over 30 years of experience designing performance road, triathlon, and mountain bikes, we felt like it was time to blaze a new trail.
