Adventure just found another gear. Introducing the GVR. Because fast is fun.

In the pursuit of more speed (and more fun) on dirt, gravel, and pavement, we sought every advantage: better aerodynamics, lighter weight, more stiffness, and exceptional comfort. We wanted to give you no excuses—whether on race day or your weekend romp. We wanted hidden cables, ample tire clearance, and precise handling. In short, we wanted it all—and we found it in the GVR

The wild spirit of gravel sends many of us down unknown backroads and trails in the pursuit of adventure. But many of us also seek speed and performance, hunting for the edge of our capabilities. So our product design team created a gravel bike with the traits that performance-hungry riders want and the toughness to handle almost any terrain.

With OBED, you can customize your build more than any other brand. Choose from Shimano or SRAM drivetrains, alloy or carbon wheels, 650b or 700c wheel and tire combos, the exact components you desire, and even a new color-blocked range of frame, fork, and graphic color options. Build your dream gravel bike from the ground up. When you customize a GVR, no two are alike—it’s built just for you.

Learn More about the GVR


This Bike Is For You If...

Finding your wild side includes a lot of race-day action. While the GVR has everything you need for the weekend adventure with friends, the nimble handling, low weight, and aerodynamic design position it neatly for performance-oriented riding. The GVR is engineered for high-speed riding on tough courses. If you like to attack steep and punchy climbs, carve through loose corners, and fly off the front of a fast group, the GVR is for you.

Material

Carbon Fiber

Weight Frame & Fork

1,525g size medium in shadow color


Learn more about the GVR with the Owner's Guide

Read GVR Stories

Frame Details

Frame Specs

Frame Material Carbon Fiber
Max Tire Size Through 700x45c or 650x53
Headset Spec FSA NO.55R
Front Spacing 12x100mm
Front Axle Specs 12x1.5x120-125mm
Rear Spacing 12x142mm
Rear Axle Specs 12x1.5x170-175mm
Seatpost Diameter 31.6mm
Seat Collar Diameter 34.9mm
BB Standard T47
Max Chainring Size 52/36t
Rotor Max Size (Front) 160mm
Rotor Max Size (Rear) 160mm
Front Derailleur Mount Braze-on
Derailleur Hanger Proprietary
Water Bottle Mounts Yes
Fender Mounts Add On Option
Rack Mounts Add On Option
Toptube Bag Mounts Add On Option
Downtube Accessory Mount Yes
Fork Offset 50mm
Rigid Fork Length 395mm
Cable Routing The GVR comes standard with internal cable routing. Contact us regarding an external routing option.

Carbon Fork

Our full-carbon adventure gravel fork is designed with performance, compliance and versatility in mind:

  • Fork Steer Tube Diameter: 1 1/8” to 1 1/2” tapered
  • Axle Spacing: 12 x 100mm
  • Compatible Rotor sizes: 140 and 160mm

Elevate your off-road experience with a fork that combines precision, comfort, adaptability, and style.

Size Chart & Geometry

Size Guide

Bike Geometry

Size XS S M L XL
Top Tube Length (mm) 518 527
544
560
581
Head Tube Length (mm) 115 128
146
170
192
Seat Tube Angle 74.5˚ 74.5˚ 74.0˚ 73.5˚ 73.0˚
Head Tube Angle 70.5˚ 70.5˚ 71.5˚ 72.0˚ 72.0˚
BB Drop (mm) 72
72
71
68
67
Chainstay Length (mm) 425
425
425
425
425
Wheelbase (mm) 1010
1016
1014
1026
1043
Front Center (mm) 596
601
600
611 628
Standover Height (cm) 74.5
76.9
80.7
83.7 86.3
Fork Axle to Crown (mm) 395 395 395 395 395
Fork Rake (mm) 50 50
50 50 50
Seat Tube Length (mm) 460
490
520
550
580
Reach (mm) 370
375 380
385 395
Stack (mm) 534
548
570
590 610

Shipping & FAQs

Shipping & Delivery Options

Obed bikes ship pre-assembled factory direct to your doorstep with a super simple setup process or delivered fully built by a technician. Learn more about our Domestic and International Shipping & Delivery Options.

Have more Shipping Questions? Check out our frequently asked shipping questions.

What should I do if I am between on two sizes?

If you can achieve your required seat height with both bikes sizes, then you can pick based on your riding preference or style. The smaller frame will be more nimble while the larger bike may feel higher and faster. LiveChat with us or email us for help finding the right size.

How do I mount accessories onto my Obed?

Our GVR model has various mounting points for a multitude of accessories available on the market.

For nutrition and hydration, our water bottle and optional top tube storage mounts can be used with most 2-hole accessories designed for M5 x 0.8mm mounts spaced 65mm apart. The screws provided with the frame are 10mm long and should be replaced with longer screws should your accessory mounting bracket be more than 3mm thick.

At the rear of the bike, we offer an optional seat stay brace for mounting. Unlike many metal bikes which may have open ended mounting points, our carbon fiber frames have closed end mounting points. This requires special attention to the length of screw when mounting racks and fenders with various thickness attachments. Should the accessory mounting point be more than 2mm thick, source screws that are 10-13mm longer than the thickness of the item you’re attaching.

We recommend a 20lb load weight limit.
